Manual 2/2-way diaphragm valve with metal body

GEMÜ 671

ConfigureTechnical data sheet
GEMÜ 671
The GEMÜ 671 2/2-way diaphragm valve has a low-maintenance plastic actuator and is manually operated. An integrated optical position indicator is standard.

Key features

  • Optional PVDF handwheel available in white (GEMÜ 611)
  • Extensive range of accessories available, e.g. electrical position indicator for open handwheel position or lockable handwheel clamp (GEMÜ 671)
GEMÜ 671

Technical features

Parameters
Value
Media temperature
-10 to 80 °C
Sterilization temperature
max. 150 °C
Ambient temperature
0 to 60 °C
Operating pressure
0 to 10 bar
Nominal sizes
DN 15 to 100
Body configurations
2/2-way body
Connection types
Clamp
Flange
Spigot
Threaded connection
Connection standards
ANSI
ASME
BS
DIN
EN
ISO
JIS
NPT
SMS
Body materials
1.4408, investment casting material
1.4408, investment casting material, PFA lined
1.4435 (316L), forged material
1.4435 (BN2), forged material
1.4435, investment casting material
1.4539 (904L), forged material
CW617N, brass
EN-GJS-400-18-LT, SG iron material
EN-GJS-400-18-LT, SG iron material, PFA lined
EN-GJS-400-18-LT, SG iron material, PP lined
Diaphragm materials
EPDM
FKM
PTFE/EPDM
PTFE/PVDF/EPDM

Downloads

22 Results
  • Data sheet GEMÜ 611, 671

    pdf, 3.91 MB, EN

  • Operating instructions GEMÜ 611, 671 611   671

    pdf, 7.11 MB, EN

  • Üzemeltetési útmutató GEMÜ 611, 671

    pdf, 1.21 MB, HU

  • 技术单页 GEMÜ 611, 671

    pdf, 895 KB, ZH

  • Especificações GEMÜ 611, 671

    pdf, 792 KB, PT

  • Betriebsanleitung GEMÜ 611, 671

    pdf, 7.14 MB, DE

  • Operating instructions GEMÜ 611, 671 (US)

    pdf, 1.57 MB, EN

  • Руководство по эксплуатации GEMÜ 611, 671

    pdf, 1.21 MB, RU

  • Instruções de operação GEMÜ 611, 671

    pdf, 1.16 MB, PT

  • Notice d'utilisation GEMÜ 611, 671

    pdf, 1.15 MB, FR

  • Datasheet GEMÜ 611, 671 (US)

    pdf, 793 KB, EN

  • Betriebsanleitung / Operating instructions GEMÜ 611, 671 611   671

    pdf, 10.57 MB, DE, EN
