Microprocessor-controlled electrical position indicator
GEMÜ 1242
Do you have any questions? Start a conversation.
Universal position indicator with long-range LEDs
Product information
The GEMÜ 1242 electrical position indicator is suitable for installation on pneumatically operated linear actuators. The position of the valve spindle is reliably electronically detected and evaluated using play-free and non-positive mounting. Intelligent microprocessor-controlled functions facilitate commissioning and support during operation. The current position of the valve is displayed via high-visibility LEDs and fed back via electrical signals. The GEMÜ 1242 has been specially designed for valves with a stroke of 2 to 46 mm.
Key features
- Fieldbus connection AS-Interface and DeviceNet (optional)
- Communication and programming interface IO-Link
- Adjustable switch point tolerances
- Speed-AP function for fast mounting and initialization
- High visibility position indicator by LED
- On-site or remote end position programming via programming input
Technical features
Parameters
Value
Ambient temperature
0 to 60 °C
Linear measuring range
2 to 75 mm
Radial measuring range
0 to 90°
Supply voltages
24 V DC
Protection class
IP 67
Electrical connection types
M12 plug
Communication modes
AS-Interface
DeviceNet
IO-Link
Conformities
ATEX
CSA
EAC
ETL Listed C US
FMEDA
IECEx
NEC 500
