Manual metal shut-off damper

GEMÜ D487 Victoria

ConfigureTechnical data sheet
Manual butterfly valve with lever handle, stainless steel disc and flange connection – ideal for water treatment, chemical and process engineering.

Soft-seated, centrally mounted butterfly valve with special materials

Product information

The GEMÜ D487 Victoria soft-seated butterfly valve is manually operated. It has a metal hand lever or gearbox depending on customer requirements. The butterfly valve is available in nominal sizes DN 25 Up to 1600 and in standardized installation lengths ISO 5752/20 | EN 558-1/20 | API 609 category A (DIN 3202 K1) in wafer, lug and U section body versions.

Key features

  • Available in large nominal sizes
  • Bubble tight sealing, in accordance with EN 12266-1/P12, leak rate A
  • Special materials for disc, seal and valve body
  • Vulcanizable liner
  • Abrasion-resistant version possible
Manual butterfly valve with lever handle, stainless steel disc and flange connection – ideal for water treatment, chemical and process engineering.

Technical features

Parameters
Value
Media temperature
-60 to 210 °C
Ambient temperature
-20 Up to 70 °C
Operating pressure
0 Up to 16 bar
Nominal sizes
DN 25 to 1600
Housing configurations
Lug
U section
Wafer
Connection standards
ANSI
AS
ASME
AWWA
BS
DIN
EN
ISO
JIS
Body materials
ASTM
EN-AC-46100, aluminium casting material
EN-AC-47100, aluminium casting material
EN-GJL-250
EN-GJS-400-15, SG iron material
EN-GJS-400-18-LT, SG iron material
S275JR, cast steel material with epoxy coating
Body coating
Epoxy
Liner materials
CR
CSM (Hypalon®)
ECO
EPDM
NBR
SBR, abrasion resistant
Silicone
Disc materials
1.4408, investment casting material
1.4469, Duplex cast steel material
1.4539, forged material
2.0975, bronze casting material
2.4602 (alloy 22), block material
EN-GJS-400-15, SG iron material
Disc coating
EPDM
Epoxy
Halar®
NBR
Rilsan®
SBR
Conformities
ACS
DNV GL
DVGW Drinking water
DVGW Gas
EAC
FDA
WRAS
