GEMÜ 611

Manually operated diaphragm valve

  • Description
  • Features
  • Technical specifications

The GEMÜ 611 2/2-way diaphragm valve has a low-maintenance plastic actuator and is manually operated. An integrated optical position indicator is standard.

  • Optional PVDF handwheel available in white (GEMÜ 611)
  • Extensive range of accessories available, e.g. electrical position indicator for "open" handwheel position or lockable handwheel clamp (GEMÜ 671)
  • Media temperature :-10 to 80 °C
  • Sterilization temperature:max. 150 °C
  • Ambient temperature:0 to 60 °C
  • Operating pressure :0 to 10 bar
  • Nominal sizes:DN 10 to 20
  • Body configurations:2/2-way body
  • Connection types:Clamp | Spigot | Threaded connection
  • Connection standards:ANSI | ASME | BS | DIN | EN | ISO | JIS
  • Body materials:1.4435 (316L), forged material | 1.4435, investment casting material | CW617N, brass
  • Diaphragm materials:EPDM | FKM | PTFE/EPDM
  • Conformities:EAC | FDA

Product video

How diaphragm valves with metal valve bodies work

00:40 min
6091 Views
Online since 16.09.2015
More videos
Valve solutions for mixing electrode slurries
Further applications

Product applications

Valve solutions for mixing electrode slurries

The first step in the manufacture of lithium-ion battery cells is to mix the electrode slurries, which are then applied to the electrode foils (anode/cathode) as a layer in the next step. The slurry comprises a mixture of active materials, solvents, binders and additives. When mixing slurry, it is particularly important to feed in the different components in precisely the correct quantities. GEMÜ has the appropriate valves, measurement and control systems to ensure the process reliability of this manufacturing step. Find out more about the slurry mixing process and how GEMÜ supports you with expert solutions in this application flyer.
