654 8D60425400TH 1830

Diaphragm valve, manual

Item number:		88792057
Description

Type	654	Diaphragm valve, manually operated, stainless steel handwheel electropolished, optical position indicator
DN	8	DN 8
Body configuration	D	2/2-way body
Connection type	60	Spigot ISO 1127 / EN 10357 series C / DIN 11866 series B
Valve body material	42	1.4435 (BN2), forged body Δ Fe < 0.5 %
Diaphragm material	54	PTFE/EPDM one-piece
Control function	0	manually operated
Actuator version	0TH	With seal adjuster and stroke limiter
Execution type	1830	Media wetted area cleaned to ensure suitability for paint applications, parts sealed in plastic bag and surface 1508
Surface	1508	Ra ≤ 0.6 μm (25 μin.) for media wetted surfaces, electropolished internal / external
Diaphragm size	8	Diaphragm size 8

Request a quotation now
To see prices login/register here

Description Features Tender specifications Documents

The GEMÜ 654 2/2-way diaphragm valve has a stainless steel bonnet and is manually operated. The valve has a handwheel made from stainless steel. An integral optical position indicator is standard.

Handwheel design allows minimal heat sink
CIP/SIP capable
Autoclave capability
Extensive range of accessories available
Opening stroke and closing stroke limiter
Handwheel locking available upon request (electric or mechanical)
Configurable with proximity switches for position feedback
