417 15D 7 1 40

Butterfly valve, manual

Item number:		88012870
Description

Type	417	Butterfly valve, manually operated
DN	15	DN 15
Body configuration	D	2/2-way body
Connection type	7	Union ends with DIN insert (socket)
Body material	1	PVC-U, grey
Seat (liner)	4	FPM
Control function	0	Manually operated
Shaft connection and size	D08	Square, diagonal, WAF 8 mm

Request a quotation now
To see prices login/register here

Description Features Tender specifications Documents

The GEMÜ 417 butterfly valve has an ergonomically designed corrosion resistant plastic hand lever. It can be protected against accidental operation by the integrated locking device.

Low weight
Corrosion resistant plastic body
Simple installation with union nut
Ergonomic handle with anti-twist system and locking device
